The DAHCC Sensors and Actuators Ontology

Metadata

URI
https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/
Publisher (s)
IDLab - imec - Ghent University
Creator (s)
Bram Steenwinckel, Mathias De Brouwer, Femke Ongenae
Version Information
0.0.1
Imports
Sensors:
https://saref.etsi.org/core/v3.1.1/
https://saref.etsi.org/saref4bldg/v1.1.2/
License
"MIT License"
Ontology RDF
RDF (xml)

Description

This ontology describes the different concepts used within the DAHCC ontology to link static sensors and actuators to their corresponding properties and locations.

This ontology uses both the saref core and saref4building ontologies as upper ontologies to define most of the concepts and adds additional classes and object properties to differentiate within the digital health space.

Table of Contents

  1. Classes
  2. Object Properties
  3. Datatype Properties
  4. Annotation Properties
  5. Namespaces
  6. Legend

Overview

Figure 1: Ontology overview

Classes ↑

AtmosphericPressure c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/AtmosphericPressure
Super-classes Pressure c

BathRoom c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/BathRoom
Super-classes Room c

BedRoom c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/BedRoom
Super-classes Room c

Blind c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Blind
Super-classes EnvironmentalState c

BrownGoods c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/BrownGoods
Super-classes core:Appliance c
Sub-classes CoffeeMaker c
Computer c
WaterBoiler c
Radio c
Tv c

Button c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Button
Super-classes EnvironmentalState c

CO2 c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/CO2
Super-classes core:Property c

CO2Sensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/CO2Sensor
Super-classes core:Sensor c

CoffeeMaker c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/CoffeeMaker
Super-classes BrownGoods c

Computer c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Computer
Super-classes BrownGoods c

ContactSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/ContactSensor
Super-classes core:Sensor c
Sub-classes DoorSensor c

DeepFreezer c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/DeepFreezer
Super-classes WhiteGoods c

Dimmer c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Dimmer
Super-classes EnvironmentalState c

DinningRoom c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/DinningRoom
Super-classes Room c

Dishwasher c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Dishwasher
Super-classes WhiteGoods c

DoorSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/DoorSensor
Super-classes ContactSensor c

ElectricalCooker c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/ElectricalCooker
Super-classes WhiteGoods c

ElectricityMeter c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/ElectricityMeter
Super-classes core:Meter c

EnergyConsumption c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/EnergyConsumption
Super-classes core:Property c

EnvironmentalState c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/EnvironmentalState
Super-classes core:Property c
Sub-classes LightSwitch c
Relay c
Button c
Blind c
Positioning c
Dimmer c

Floor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Floor
Super-classes saref4bldg:BuildingSpace c

Fridge c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Fridge
Super-classes WhiteGoods c

Garage c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Garage
Super-classes saref4bldg:BuildingSpace c

Garden c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Garden
Super-classes saref4bldg:BuildingSpace c

Humidity c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Humidity
Super-classes core:Property c
Sub-classes RelativeHumidity c

HumiditySensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/HumiditySensor
Super-classes core:Sensor c

IndoorTemperature c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/IndoorTemperature
Super-classes Temperature c

Kitchen c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Kitchen
Super-classes Room c

Light c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Light
Super-classes core:Property c

LightSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/LightSensor
Super-classes core:Sensor c

LightSwitch c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/LightSwitch
Super-classes EnvironmentalState c

LivingRoom c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/LivingRoom
Super-classes Room c

Localisation c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Localisation
Super-classes core:Property c

Loudness c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Loudness
Super-classes Noise c

LoudnessSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/LoudnessSensor
Super-classes core:Sensor c

Microwave c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Microwave
Super-classes WhiteGoods c

Motion c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Motion
Super-classes core:Property c

MovementSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/MovementSensor
Super-classes core:Sensor c
Sub-classes PresenceSensor c

Noise c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Noise
Super-classes core:Property c
Sub-classes Loudness c

OutdoorTemperaturee c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/OutdoorTemperaturee
Super-classes Temperature c

Oven c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Oven
Super-classes WhiteGoods c

PeopleNumber c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/PeopleNumber
Super-classes Presence c

PeoplePresencee c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/PeoplePresencee
Super-classes Presence c

Positioning c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Positioning
Super-classes EnvironmentalState c

Power c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Power
Super-classes core:Property c

Presence c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Presence
Super-classes core:Property c
Sub-classes PeopleNumber c
PeoplePresencee c

PresenceSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/PresenceSensor
Super-classes MovementSensor c

Pressure c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Pressure
Super-classes core:Property c
Sub-classes AtmosphericPressure c

PressureSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/PressureSensor
Super-classes core:Sensor c

Radio c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Radio
Super-classes BrownGoods c

RainRate c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/RainRate
Super-classes Weather c

RainrateSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/RainrateSensor
Super-classes core:Sensor c

RelativeHumidity c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/RelativeHumidity
Super-classes Humidity c

Relay c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Relay
Super-classes EnvironmentalState c

Room c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Room
Super-classes saref4bldg:BuildingSpace c
Sub-classes BedRoom c
Kitchen c
StorageRoom c
LivingRoom c
Toilet c
DinningRoom c
BathRoom c

Socket c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Socket
Super-classes core:Device c

StorageRoom c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/StorageRoom
Super-classes Room c

Temperature c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Temperature
Super-classes core:Property c
Sub-classes OutdoorTemperaturee c
IndoorTemperature c

TemperatureSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/TemperatureSensor
Super-classes core:TemperatureSensor c

Toilet c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Toilet
Super-classes Room c

Tv c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Tv
Super-classes BrownGoods c

VOC c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/VOC
Super-classes core:Property c

VOCSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/VOCSensor
Super-classes core:Sensor c

VentilationLevel c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/VentilationLevel
Super-classes core:Property c

WashingMachine c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WashingMachine
Super-classes WhiteGoods c

WaterBoiler c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WaterBoiler
Super-classes BrownGoods c

WaterRunning c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WaterRunning
Super-classes core:Property c

WaterRunningSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WaterRunningSensor
Super-classes core:Sensor c

Weather c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/Weather
Super-classes core:Property c
Sub-classes RainRate c
WindSpeed c

WhiteGoods c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WhiteGoods
Super-classes core:Appliance c
Sub-classes DeepFreezer c
Fridge c
ElectricalCooker c
Microwave c
Dishwasher c
Oven c
WashingMachine c

WindSpeed c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WindSpeed
Super-classes Weather c

WindSpeedSensor c # Classes

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/WindSpeedSensor
Super-classes core:Sensor c

Pump c # Classes (external)

URI https://saref.etsi.org/saref4bldg/Pump
Super-classes core:HVAC c

Object Properties ↑

isLocatedNear op # OPs

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/isLocatedNear

stateAnalysedBy op # OPs

URI https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/stateAnalysedBy

Annotation Properties ↑

creator ap # APs (external)

URI http://purl.org/dc/elements/1.1/creator

publisher ap # APs (external)

URI http://purl.org/dc/elements/1.1/publisher

creator ap # APs (external)

URI http://purl.org/dc/terms/creator

description ap # APs (external)

URI http://purl.org/dc/terms/description

issued ap # APs (external)

URI http://purl.org/dc/terms/issued

license ap # APs (external)

URI http://purl.org/dc/terms/license

modified ap # APs (external)

URI http://purl.org/dc/terms/modified

publisher ap # APs (external)

URI http://purl.org/dc/terms/publisher

source ap # APs (external)

URI http://purl.org/dc/terms/source

title ap # APs (external)

URI http://purl.org/dc/terms/title

preferredNamespacePrefix ap # APs (external)

URI http://purl.org/vocab/vann/preferredNamespacePrefix

preferredNamespaceUri ap # APs (external)

URI http://purl.org/vocab/vann/preferredNamespaceUri

hadPrimarySource ap # APs (external)

URI http://www.w3.org/ns/prov#hadPrimarySource

Namespaces ↑

default (:)
https://dahcc.idlab.ugent.be/Ontology/SensorsAndActuators/
Sensors
https://dahcc.idlab.ugent.be/Ontology/Sensors/
brick
https://brickschema.org/schema/Brick#
core
https://saref.etsi.org/core/
csvw
http://www.w3.org/ns/csvw#
dc
http://purl.org/dc/elements/1.1/
dcam
http://purl.org/dc/dcam/
dcat
http://www.w3.org/ns/dcat#
dcmitype
http://purl.org/dc/dcmitype/
dcterms
http://purl.org/dc/terms/
doap
http://usefulinc.com/ns/doap#
foaf
http://xmlns.com/foaf/0.1/
odrl
http://www.w3.org/ns/odrl/2/
org
http://www.w3.org/ns/org#
owl
http://www.w3.org/2002/07/owl#
prof
http://www.w3.org/ns/dx/prof/
prov
http://www.w3.org/ns/prov#
qb
http://purl.org/linked-data/cube#
rdf
http://www.w3.org/1999/02/22-rdf-syntax-ns#
rdfs
http://www.w3.org/2000/01/rdf-schema#
saref4bldg
https://saref.etsi.org/saref4bldg/
sdo
https://schema.org/
sh
http://www.w3.org/ns/shacl#
skos
http://www.w3.org/2004/02/skos/core#
sosa
http://www.w3.org/ns/sosa/
ssn
http://www.w3.org/ns/ssn/
time
http://www.w3.org/2006/time#
vann
http://purl.org/vocab/vann/
void
http://rdfs.org/ns/void#
xsd
http://www.w3.org/2001/XMLSchema#

Legend

c Classes
op Object Properties
fp Functional Properties
dp Data Properties
ap Annotation Properties
p Properties
ni Named Individuals
